Boards made in 24 hours:
- up to 10 layers
- max order area 16 dm²
- min hole 0,2mm
- up to 10 000 holes per order
- green solder mask
- single boards or panels, if panel is composed by customer and panel gerbers sent
- no blind or buried vias, no multipanel
Boards made in 48 hours:
- up to 16 layers
- max order area 33 dm²
- min hole 0,2mm
- up to 25 000 holes per order
- green solder mask
- single boards or panels, if panel is composed by customer and panel gerbers sent
- no blind or buried vias, no multipanel
Boards made in 72 hours:
- up to 24 layers
- max order area 33 dm²
- min hole 0,2mm
- up to 35 000 holes per order
- green solder mask
- single board, panel or multipanel – all options available
- panelization by request for single board
- no blind or buried vias, no half-cut slots/holes
Express order with all files must be placed and confirmed no later than 12:00 (GMT+2).
The customer bears full responsibility for the designs found in the gerber files. The manufacturer does not take responsibility for flaws found in the design.
Manufacturing time for boards with blind and buried vias starts from 5 WD!
Need a board with blind and/or buried vias urgently?
We’ll manufacture boards with blind or buried vias in 5 WD, if there are:
- up to 12 layers;
- min via 0,2mm;
- holes per an order 30 000 or less;
- maximum order area 360 x 460 mm.
Feel free to place an inquiry at sales@brandner.ee!
